MODERNIZED SURFACE GEOPHYSICAL MEASUREMENT SYSTEM GEOKIN-M
The system is designed to record the activation of perforating and explosive equipment during well perforating and blasting operations in oil, gas and water wells. Activation is detected by recording vibration signals using a primary measuring transducer—an accelerometer.
-
1. Analog-to-Digital Converter (ADC)
-
2. Primary Transducer (PT)
-
3. Connecting Cable
-
4. Magnet
-
5. Mounting Stud
-
1. The instrument operates by converting an incoming analog voltage signal into a digital signal using an analog-to-digital converter (ADC). The instrument is an electronic circuit implemented on a printed circuit board. Each instrument is equipped with two analog inputs for connecting primary transducers.
-
2. The measured parameters are displayed in the PC software application.
-
3. The primary measuring transducer—an accelerometer (PT)—is secured to the metal surface of the wellhead using a magnet.
-
4. The ADC is positioned at the required distance using the connecting cable and is connected to a personal computer via USB. The required software must be installed in advance.
-
5. The instrument is switched to the required operating mode to record the activation of the perforating and explosive equipment.
-
6. The activation event is identified on the monitor by a characteristic spike in the signal amplitude.
-
7. The software generates a real-time graph and allows specific time intervals to be selected for subsequent data processing.
ADC TECHNICAL SPECIFICATIONS
ADC METROLOGICAL SPECIFICATIONS
PRIMARY TRANSDUCER TECHNICAL SPECIFICATIONS
PRIMARY TRANSDUCER METROLOGICAL SPECIFICATIONS
EXAMPLES OF RECORDED OPERATING SIGNALS
Pressure Generator, Tubing-Conveyed
Perforating Gun, Tubing-Conveyed
Pressure Generator, Two-Assembly Configuration, Tubing-Conveyed
KPG URAGAN System—New-Interval Perforation and Gas-Dynamic Formation Fracturing, Tubing-Conveyed
SYSTEM ADVANTAGES
Compact Design
The system’s compact dimensions and low weight simplify transportation and storage
Software
Fully adapted to the requirements of the oil and gas industry. The software enables real-time signal monitoring and allows recorded data to be saved in the required format
Ease of Operation
The system connects to a PC via a USB port, with all subsequent operation performed through the dedicated software
The instrument’s software functionality can be expanded to provide additional measurement capabilities:
-
Frequency Counter
-
Oscilloscope
-
AC Voltmeter
