PERFORATION / VECTOR
PKN64/114 VEKTOR PERFORATING SYSTEMS
The PKN64/114 VEKTOR product range comprises a series of single-use, carrier-type shaped-charge perforating guns in sizes from 64 to 114 mm, featuring a standardized design. The perforating guns can be conveyed to the perforation interval either on a wireline or on coiled tubing with an internal diameter of at least 50 mm.
Wireline-conveyed perforating guns can be assembled in multi-section configurations and initiated using a PVPD-N-type firing cartridge installed either at the bottom or at the top of the perforating gun.
Coiled-tubing-conveyed perforating guns are initiated using an IG1- or IG2-type initiating head.
Wireline-conveyed perforating guns can be assembled in multi-section configurations and initiated using a PVPD-N-type firing cartridge installed either at the bottom or at the top of the perforating gun.
Coiled-tubing-conveyed perforating guns are initiated using an IG1- or IG2-type initiating head.
PKN64 Perforating Gun
Compatible with VEKTOR64GP(BO) shaped charges
PKN73 Perforating Gun
Compatible with VEKTOR73GP(BO) shaped charges
PKN89 Perforating Gun
Compatible with VEKTOR89GP(BO)(SO) shaped charges
PKN102 Perforating Gun
Compatible with VEKTOR102GP(BO)(SO) shaped charges
PKN114 Perforating Gun
Compatible with VEKTOR102GP(BO)(SO) shaped charges
TECHNICAL SPECIFICATIONS
VEKTOR SHAPED CHARGES
The shaped charges are available in two versions, differing in liner material and explosive mass:
VEKTOR 64/73/89/102/105 BO
Designed to create large-diameter perforation channels through the casing and formation rock for subsequent hydraulic fracturing.
VEKTOR 64/73/89/102/105 GP
Designed to create deep penetration channels in the formation rock.
VEKTOR BO Shaped Charge
VEKTOR GP Shaped Charge
TECHNICAL SPECIFICATIONS
